Non-Contactable Voltage Detector

Safety You Can Wear, Protection You Can Trust.

he Non-Contactable Voltage Detector is a vital safety companion for electrical workers, designed to prevent potentially fatal high-voltage shocks. Worn as a wrist device, it continuously monitors the surrounding area for dangerous voltage levels. When the wearer approaches a high-voltage source, the detector activates visual (LED) and audible alarms at a calibrated safe distance, depending on the detected voltage. This early warning system helps workers maintain a secure perimeter, enhancing workplace safety in high-risk electrical environments such as overhead lines and unshielded cables.

Key Advantages

Instant Voltage Detection

Stay alert around live wires.

Maximum Safety

Dual alerts (LED + buzzer) keep you protected.

Wearable & Convenient

Hands-free wrist design for comfort.

360° Coverage

Detects voltage from any direction.

Long Battery Life

Up to 10 months standby.

Specifications

PARAMETERS DETAILS
Alarm Voltage Range 230VAC to 500kVAC
Working Frequency 50Hz / 60Hz
Visual Indicator LED light
Audible Buzzer 75 dB @ 1m
Operating Temperature -10°C to +45°C
Dimensions (H×W×D) 50mm × 45mm × 20mm

Voltage Detection Range & Safe Distances

Voltage Level (V) Safe Distance (m)
110 V 0.01 m
230 V 0.023 m
10 kV 0.5 m
35 kV 1.2 m
110 kV 2.2 m
